Blue Color 2Pin Gold Plated IP67 Waterproof Connector,M25 2 Pin Waterproof Plug
Description:
M25 IP67 wateproof connector is one of best-selling series products made with PA66 plastic, to ensure the high stability and multi-core structures. They are one of the cost-effective series for multiple applications.
How to Choose the correct connectors:
- Confirm Current Rating and Number of Contacts
- Confirm Assembly style
- Confirm Cable Wire guage
-
Confirm Cable Length and Material.
| Technical Parameters |
| Contact Resistance | 10 mΩ max |
| Insulation Structure | 500 MΩ at 500VDC |
| Operating Temperature | -40°C ~ +105°C |
| IP Class | IP67 (1m / 30min) |
| Mold Material | PA66 |
| Contact/Terminal Material | Gold Plated Brass |
| Seal Material | Silicone |
Different connection types supported:
Male plug to female inline connector
Female plug to male inline connector
Male plug to female socket
Female plug to male socket
Cable assembly is supported.
| Operation Parameters |
| Voltage Rating | 600VAC max |
| Current Rating | 50A max |
| Min Wire Size OD | 6.5mm ~ 10mm |
| Max Wire Size OD | 10.5mm ~ 18mm |
| Max.Cable Cross Section Area | 0.5mm2 ~ 6.0mm2
|
M25 waterproof Circular connector is the perfect solution to make your own waterproof connection cables easily. Thanks to its size enough based terminal, soldering and installation just takes a few minutes.
Once assembled, the M25 Outdoor Waterproof Circular Conector is easy to plug and play while keeping the elements and water out of splices and junctions. To disconnect, just unscrew the main body and pull apart the two ends.The M25 Waterproof conector has multiple waterproofing levels, consisting of o-rings, waterproof sealant, and flexible end seals designed to tighten and close when lock to together.
